PRO AIR CLASSIFIER
AVAC SERIES
Propel Pro Air Classifier offers the most efficient dry – classifying solution to remove fines from natural sand or crushed sand. It combines gravitational, inertial, centrifugal and aerodynamic forces to efficiently classify materials to increase productivity.

WATCH VIDEO
TECHNICAL DATA
| SERIES | UNITS | AVAC 100 | AVAC 150 | AVAC 200 |
|---|---|---|---|---|
| Diameter | mm (inch) |
3100 (122.0) |
3800 (149.6) |
4350 (171.3) |
| Feed Size (Max.) | mm (inch) |
6 (0.2) |
6 (0.2) |
6 (0.2) |
| *Capacity | TPH | 60 - 70 | 90 - 120 | 120 - 160 |
| Air Flow | cfm | 200 - 400 | 300 - 600 | 400 - 850 |
| Moisture (Max.) | % | 2 | 2 | 2 |
| Motor Power | kW (hp) |
30 60 |
45 60 |
55 75 |
| Weight | kg (Ton) |
11200 (11.2) |
15700 (15.7) |
17000 (17.0) |
*Details may vary based on application
Note: All the above technical details may vary at any time during engineering process & design development
